To find the Solid Tools, look in the following parts of the SketchUp interface: Solids toolbar; Tools menu (Select Tools Outer Shell or Select Tools Solid Tools and select the other tools from a submenu) Tool palette (macOS) Solids toolbar in the left-hand tray; Solid Inspector utility in the right-hand panel.

In the Entity Info dialog box that appears, the upper-left corner indicates if the selection is a solid, as shown in the figure. If you’re having trouble identifying leaks that prevent your model from working as a solid entity, you can use Solid Inspector (a utility available for paid subscribers) to inspect and fix solid modeling problems.Check out the following table for a quick introduction to the Solid Tools, including what the tool does and whether it’s available in SketchUp Free. ToolNameWhat It DoesIncluded in SketchUp Free?Outer ShellLeaves only the outer faces of overlapping solids.YesUnionCombines two or more solids into a single form.Paid subscriptions onlySubtractOne solid removes part of another and is deleted.Paid subscriptions only. Tip: Because an outer shell reduces a model’s geometry, creating an outer shell is helpful when you need to boost SketchUp’s performance.For example, say you have two models: One is a detailed interior and exterior building model. The other model illustrates the building in a street view that shows surrounding buildings, streets, and landscaping.

You can import the detailed building model into your street view. However, all that geometry might slow down your street view model and isn’t necessary. In your street view, creating an outer shell of the building eliminates the interior geometry you don’t need so that your street view model is lighter and renders faster as you work on it.To create an outer shell from overlapping groups or components, follow these steps:. With the Select tool ( ), select all the intersecting groups or components you want to include in your outer shell. Context-click your selection and choose Outer Shell from the menu that appears, as shown in the figure. The outer faces remain.Or, you can create an outer shell as follows:. Select the Outer Shell tool ( ).

Admittedly, some Xbox owners haven't played it, so I can't dock this relic for its age, but it is fair to compare MVC2 to the less pixilated, more balanced, online-enabled, and just plain superior Capcom vs. Street Fighters of the less insane variety, but MVC2 is still an enjoyable, silly fighter. Against that heavyweight, this codger has no chance.

Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash. When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip. Click to select the first group or component in your outer shell. Click the second group or component. SketchUp combines your selections into an outer shell so that only the outer faces remain. (Optional) Continue clicking additional groups or components to add them to your outer shell, as shown in the figure. Select the Outer Shell tool ( ) from the left hand tool tray.

Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash. When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip.

Click to select the first group or component in your outer shell. Click the second group or component. SketchUp combines your selections into an outer shell so that only the outer faces remain. (Optional) Continue clicking additional groups or components to add them to your outer shell, as shown in the figure. Note: The result of an outer shell is similar to the result of a union. However, the result of an outer shell contains only external faces, whereas a union can also contain internal geometry.

The following figure shows two square tubes on the left, a union of the tubes in the center, and an outer shell of the tubes on the right.Uniting solids into a single formA union merges two or more solid entities into a single solid.The result of a union is similar to the result of an outer shell. However, the result of a union can contain internal geometry whereas an outer shell contains only external faces. (See the preceding figure for an example.)Here’s how to use the Union tool to combine solid entities:. Select the Union tool ( ). Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash. When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip. Click to select the first group or component for the union.

Click the second group or component. The resulting union of the geometry remains.

(Optional) Continue clicking additional groups or components to add them to the union, as shown in the figure, which uses X-Ray view so that you can see the geometry within each solid. Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash. When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip. Click to select the cutting group or component. In the example shown here, select the peg first to make a hole in the board.

After you make a selection, the 1 next to the cursor becomes a 2. Click the group or component that you want to cut. The cutting group disappears, but makes a hole in the second selection. In this example, you see a peg-sized hole in the board. Tip: Instead of following the preceding steps, you can preselect your solid entities, context-click the selection, and choose Solid Tools Subtract from the menu. SketchUp uses the order in which you select each solid entity to determine which is the cutting entity and which entity is cut.If you’re using SketchUp Free, you can create the effect of a subtraction by using the Intersect with Model command.

When you use Intersect with Model, the two shapes don’t need to be solid entities. (If fact, Intersect with Model applies a different effect if your shapes are solids, as explained a little later in this section.) However, when you create a subtraction with the Intersect with Model command, the process requires a few more steps than the process with SketchUp Pro’s Subtract tool.Here’s how to create a subtraction with the Intersect with Model command:. Create two distinct volumes, such as a box and a cylinder.

(See and for help.). With the Select tool ( ), triple-click the first volume, which will be your cutting object. In this example, the cutting object is the cylinder, as shown in the figure.

Move and rotate your cutting shape so that it intersects with the shape you’d like to cut. (See and ) Leave your cutting shape selected, as shown in the figure. Context-click the cutting shape, and choose Intersect Faces With Model from the menu that appears. The command tells SketchUp to create edges where the two shapes intersect. With the Eraser tool ( ), erase or move the geometry that you don’t want to keep. In the following figure, you see how the box shape is changed after the cylinder is erased.

Tip: Remember you can hold down the scroll wheel on your mouse to temporarily switch to the Orbit tool, so you can orbit around and find all the geometry you want do delete. (See for details about the Eraser tool.)Intersect with Model creates edges in the current context. If your shapes are groups or components, you can create the intersecting lines either within the group or outside it. When you create the intersecting lines outside a group’s context, you can easily separate your original shapes from the edges that SketchUp creates, as shown in the following figure. See for details about groups and for an introduction to groups and components, respectively.Trimming one solid with anotherWith the Trim tool, you cut one solid entity with another, just like a subtraction. However, when you use the Trim tool, the cutting solid remains in the model.

So, if you use a peg to trim a board, the peg remains after it cuts the board. Like all the Solid tools, the Trim tool works only if two solid entities overlap.

Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash. When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip. Click to select the cutting group or component. In the example shown here, select the peg first to make a hole in the board. After you make a selection, the 1 next to the cursor becomes a 2.

Click the group or component that you want to cut. The cutting group remains, but makes a hole in the second selection. The result is hard to see at first (refer to Callout 1). However, move the peg out of the hole, as shown in Callout 2, and you see the hole in the board.Leaving only the intersecting geometryWith SketchUp Pro’s Intersect tool ( ), you select two or more overlapping solid entities, and only the intersecting geometry is left behind.To perform an intersection, follow these steps:.

Select the Intersect tool ( ). Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash ( ). When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip. Select a solid entity that you want to use in the intersection. Select one or more additional solids that overlap your initial selection. The resulting intersecting geometry remains.

In this example, the intersection of the box and the sphere (Callout 1) creates a point with a rounded base (Callout 2). Tip: Until you hover over a solid group or component, you see an arrow cursor with a circle and a slash. When your cursor hovers over a solid group or component, the red circle and slash change to a black 1 inside a circle, and you see a Solid Group or Solid Component ScreenTip. Click a solid entity. Click another solid entity that intersects your first selection.

SketchUp splits all the geometry along the edges where the selected solids intersect. For example, in the figure, the two groups shown on the left split into 3 groups, as shown on the right.Fixing models with Solid InspectorAs geometry gets more and more complex, small errors may prevent models from being manifold. Solid Inspector in SketchUp for Web is a utility that helps you prepare models for 3D printing by finding and fixing problems that prevent SketchUp from classifying your model as a solid. This inspection is also useful for fixing 3D models for Solid Tool operations.

Note: Solid Inspector is available for paid subscribers. In SketchUp Pro, the Solid Inspector extension performs a similar function. Activate Solid InspectorFind the Solid Inspector utility at the bottom of the right-hand panel menu in SketchUp for Web. When you activate the utility, you’ll be prompted to select a group or component. With a selected object, click Run Inspector to proceed.
